CINO čtečka F680BT-SR bezdrátová 1D čtečka kódu, dosah 100m, USB kit vč. základny + kabel
Kód: 3058121
Doprava zadarmo
Pri nákupe nad 100 € máte u nás dopravu zadarmo.
Overený obchod
Viac ako 10 000 zákazníkov nás odporúča.
Spokojnosť
Spokojný zákazník je náš prvoradý cieľ.
Všetko skladom
Viac ako 50 000 produktov skladom pre rýchle doručenie.
Súvisiaci tovar
Podrobný popis
F680BT kombinuje exkluzivní zobrazovací technologii společnosti Cino s bezdrátovou mobilitou, kterou nabízí Bluetooth. Poskytuje vynikající čtecí výkon na široké škále 1D čárových kódů a skládaných symbolů. Ve spojení s inteligentní kolébkou nabízí tento scaner bezdrátový pracovní dosah přes 100 metrů. Ať už skenujete položky na pultu nebo kontroluje stav zásob v depu, F680BT pomůže pracovníkům splňit svou úlohu s hvězdnou efektivitou.
| Performance Characteristics | |
| Optical System | High performance linear imaging engine |
| Print Contrast | 15% minimum reflective difference |
| Light Source | 630nm LED |
| Minimum Resolution | 3 mil (Code 39, PCS 0.9) |
| Reading Range *1 | 13 mil (0.33mm) UPC/EAN up to 24” 20 mil (0.5mm) Code 39 up to 34” |
| Scan Rate | Dynamic scanning rate up to 500 scans per second |
| Reading Direction | Bi-directional (forward and backward) |
| Pitch / Skew / Tilt | ±65° / ± 65° / ± 55° |
| Operating Modes | Trigger, Presentation |
| Configuration Setup | Command barcodes iCode FuzzyScan PowerTool |
| Data Editing | DataWizard Premium |
| User Interfaces | Blue link indicator and 2-color status indicator Programmable beeper Optional vibrator |
| Electrical Characteristics | |
| Battery | 3.7V, 2600mAH Li-ion rechargeable battery |
| Battery Charge Time | Approx. 4 ~ 5 hours per full charge |
| Scans per full Charge | More than 126,000 scans and transmissions |
| Operating Voltage | 5VDC ± 10% |
| Operating Current | Charging: Max.680 mA Standby: Max.85 mA (Scanner with Smart Cradle) |
| Communication Characteristics | |
| RF Standard | Bluetooth v4.0 |
| RF Frequency Band | 2.402 ~ 2.4830 GHz unlicensed ISM band |
| Radio Link Modes | PAIR, PICO, SPP, HID |
| Communication Range | More than 100 meters in open space when working with Smart Cradle, line of sight |
| Supported Profiles | SPP, HID |
| Physical Characteristics | |
| Dimensions | 97.0 mm (L) x 65.0 mm (W) x 156 mm (D) 3.81 in. (L) x 2.55 in. (W) x 6.14 in. (D) |
| Weight | 198g (Battery included) |
| Color | Light Gray or Black |
| Supported Symbologies | |
| 1D Linear Codes | Code 39, Code 39 Full ASCII, Code 32, Code 39 Trioptic Code 128, GS1-128, Codabar, Code 11, Code 93 Standard & Industrial 2 of 5, Interleaved & Matrix 2 of 5 German Postal Code, China Postal Code, IATA UPC/EAN/JAN, UPC/EAN/JAN with Addendum Telepen, MSI/Plessey & UK/Plessey GS1 DataBar (formerly RSS) Linear & Linear Stacked. |
| Linear-stacked | PDF417, Micro PDF417, Codablock F, Composite |
| User Environment | |
| Drop Specifications | Withstands multiple drops from 1.8m (6.0ft) to concrete |
| Environmental Sealing | IP42 |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Ambient Light Immunity | 0 ~ 100,000 Lux |
| ESD Protection | Functional after 15KV discharge |
| Safety & Regulatory | |
| EMC & Radio | CE, FCC, BSMI, C-Tick, KC, NCC, VCCI, MIC |
| Safety *2 | LED Eye Safety IEC62471, Exempt Group |
| Environmental | Compliant with RoHS directive |
| Accessories | |
| Smart Cradle RF Standard: Battery Charging: User Interfaces: Host Interface: |
Bluetooth v4.0 Fast charge 1 blue link indicator 2-color status indicator Beeper, Paging / Reset button USB HID (USB Keyboard) USB VCOM (USB COM port emulation) Standard RS232 |
| Charging Cradle Battery Charging: User Interface: |
Fast charge 1 blue power indicator |
Dodatočné parametre
| Kategória: | Bezdrôtové čítačky |
|---|---|
| Záruka: | 2 roky |
| Hmotnosť: | 0.01 kg |
| Druh kódu: | 1D (čiarový kód) |
| Typ snímača: | Imager |
| Rozhranie: | USB |
